Termékinformációk

TU 50 TF Take-up ball bearing unit with composite or cast metal housing Részletes technikai adatokért KATTINTSON IDE!

Termék jellemzők

Sorok száma0
FuratHengeres
Tömítés típusaKontakt
Kenés típusaZsír
AnyagaCsapágyacél
Dinamikus alapterhelés35.1 kN
Statikus alapterhelés23.2 kN
Határfordulatszám4000 r/min

Részletes leírás

Take-up ball bearing units consisting of an insert bearing mounted in a composite or cast metal housing. The units are typically mounted in take-up frames and adjusted by an adjustment screw. In addition to being part of a unit, some take-up housings for insert bearings are available as separate components. The SKF assortment includes take-up ball bearing units compliant with several industrial standards, as required by many industrial applications.

Ready to mount;Lubricated and sealed bearings;Quick locking on the shaft;Large variety of housing shapes, housing materials, and locking methods;Concentric locking options for high speeds and low vibration
