Termékinformációk

RNU 203 ECP Single row cylindrical roller bearing, NU design, without inner ring Részletes technikai adatokért KATTINTSON IDE!

Termék jellemzők

Belső átmérő mm22.1 mm
Külső átmérő mm40 mm
Szélesség mm12 mm
Sorok száma1
FuratHengeres
PontosságNormal
TömítésNincs
Tömítés típusaNem alkalmazható
Kenés típusaNincs
Dinamikus alapterhelés20 kN
Statikus alapterhelés14.3 kN
Határfordulatszám22000 r/min

Részletes leírás

Single row cylindrical roller bearings of the NU design without an inner ring consist of an outer ring with a roller and cage assembly. They are typically used in applications where hardened and ground raceways are provided on the shaft. Without the inner ring, a larger shaft diameter can be used to provide a stronger, stiffer shaft. The bearings can accommodate axial displacement in both directions, limited only by the width of the raceway on the shaft.

High radial load carrying capacity;Enable a stronger, stiffer shaft;Low friction;Long service life;Accommodate axial displacement in both directions
SKF AB
