Termékinformációk

NUTR 1542 X Support roller (yoke-type track roller) with flange rings, integral sealing and relubrication feature Részletes technikai adatokért KATTINTSON IDE!

Termék jellemzők

Belső átmérő mm15 mm
Sorok száma2
Tömítés típusalabirintus tömítések
Kenés típusaZsír
AnyagaCsapágyacél
Dinamikus alapterhelés20.1 kN
Statikus alapterhelés23.2 kN
Határfordulatszám5000 r/min

Részletes leírás

Support rollers (yoke-type track rollers) are designed to run on all types of tracks and to be used in cam drives, conveyor systems, etc. They are based on a double row full complement cylindrical roller bearing with an inner ring and have a thick-walled outer ring with a cylindrical running surface. They are supplied sealed and ready-to-mount. The inner ring contains a lubrication hole to facilitate relubrication.

High radial load carrying capacity;Accommodate relatively heavy axial loads due to skew or tilting;Long service life;Ready to mount;Sealed for increased reliability, with relubrication feature
SKF AB
